Verado Gen-C Pump Power Steering Rigging Kit - Single Engine - 8M0151557

Verado Gen-C Pump Power Steering Rigging Kit - Single Engine - 8M0151557

This kit includes the new style Mercury Gen C power steering pump assembly (8M0199048). This kit comes with the Tilt 40 CM3 Helm (8M0137447) steering helm (tilt model) and Single Engine Pump Installation Kit (8M0199050).

 Additionally, you may need:

• Power Harness
• Signal Harness
• Hoses Pump to Helm
• Hoses - Helm to Steering Cylinder/Bulkhead Fittings
• Bulkhead Fittings

Single Engine (Single Steering Cylinder) Installations:

• Mercury 150 4-Stroke and Optimax 2-Stroke Engines
• Mercury Verado 135-200 (L4) Engines
• Mercury Verado 200-400 (L6) Engines
• Mercury 4-Stroke CMS 175-225 (V6) Engines
• Mercury 4-Stroke CMS 250-300 (V8) Engines
• Mercury Verado 250-300 (V8) Engines
• Mercury Verado 350-400 (V10) Engines
• Mercury Verado 450R-500R (V8) Engines

Alternative Part #: 892560K35

Tilt Helm Installation Instructions

Power Steering Pump Gen C Instructions

Recommendations for Hose Routing

Rigging Center Instructions
